5. Troubleshooting
Code 6025: “Board id: input 4 write error” (Error)
Situation Solution
Malfunction input board. The
projector can not write to the
installed input board.
Replace the input board.
Malfunction I²C communication on
the P MP board. Other input boards,
the Display board, the WARP module
and the Input & Comm unication unit
also have “Board id read errors”.
Remove/disconnect the other boards from the I²C com munication line one by on e and
check if this error remains. R ep lace the boa rd which makes this error goes away. If none
of the boards is the cause of this error, replace the PMP board. See chapter XX XX , to
see which boards are c onnected to the same internal communication line.
Code 6026: “Board id: input 4 not calibrated” (Warning)
Situation Solution
The installed input board has no
calibration values stored. The
projector will use default calibration
values for this input board.
No actions required. Parameters can be adjus ted for the Analog Video applied on t he
DVI connector. See projector ’s user guide.
Code 6027: “Board id: input 4 type on wrong location” (Warning)
Situation Solution
Board type data found on unusual
memory location
No further action needed. Board will operate normally.
Code 6028: “Board id: pmp unknown format” (Warning)
Situation Solution
Old projector softwa re installed. Th e
ID parameters of the pmp board
are written in a format w hich is not
known by the projector software.
Check if the v ersion o f the installed projector software is the latest available v ersion. T he
latest version can be downloaded from h
ttps://my.barco.com.
Corrupt pr ojector s oftware. Reinstall the latest projector software.
Code 6029: “Board id: pmp not accessable” (Error)
Situation Solution
Only the ID parameters of the pixel
mapping processor (PMP ) board
and one of the other boards in the
projector are not acc essible.
First troubleshoot the other “Board id” error. S ee troubleshoo ting checklist of the
corresponding error code.
The Con troller can not access the
ID parameters of any board in the
projector. T his may indicates a
malfunction I²C functionality on the
PMP board. Note that the PMP and
Controller are physical on the same
board located.
Replace the PMP b oard. See "Replacing the PMP board", page 156.
The Controller c an not access the ID
parameters of the PMP but the ID
parameters of all other boards are
access ib le .
Ignore this error message unless other functionality of the PMP fails as well. If so,
replace the PMP board.
Code 6030: “Board id: pmp read error” (Error)
Situation Solution
Malfunction I²C communication on
the P MP board. Other input boards,
the Display board, the WARP module
and the Input & Comm unication unit
also have “Board id read errors”.
Remove/disconnect the other boards from the I²C com munication line one by on e and
check if this error remains. R ep lace the boa rd which makes this error goes away. If none
of the boards is the cause of this error, replace the PMP board. See chapter XX XX , to
see which boards are c onnected to the same internal communication line.
R5905312 HDF W SERIES 24/01/2013 43
