Chapter 6: Operation
Setting Other Weld Parameters
6-38 011-003-991 EN
If you chose Off, continue setting
other parameters in the menu.
If you chose On, use the Select keys
and the numeric keypad to enter the
values you want to use as Afterburst
parameters.
Use Select keys and the numeric
keypad to set the following criteria
for the afterburst:
AB Delay (s): Set the delay (in sec-
onds) to wait after the end of the hold
time until the start of the afterburst.
Suggested minimum value is 0.1
second.
AB Time (s): Set the Time (in sec-
onds) of the afterburst.
AB Amplitude(%): Set the amplitude
(as a percentage of the maximum) to
be used during the afterburst.
Press the Go Back/Esc key to exit
the submenu.
WELD SETUP Pg6of13
Amplitude(%) =100
Pretrigger> Off
Afterburst> Off
Select
Select
Select
AFTERBURST Pg1of1
AB Delay(s) =0.010
AB Time(s) =0.010
AB Amplitude(%) =100
Select
Select
Select
