2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Other Weld Parameters
011-003-991 EN 6-37
Setting the Afterburst
You can select whether there will be a burst of ultrasonic energy after welding is complete.
If you select ON, you can also set the delay and length of the afterburst (in seconds), and
the amplitude that will be used.
Take this action… To get this result…
Using the arrow keys, scroll downward
through the menu until you see Afterburst.
Press the Select key that corresponds to
Afterburst.
Press the same Select key again to toggle
between On and Off.
Press Enter on the numeric keypad to save
the new value, or press Go Back/Esc to
make no change to the value.
WELD SETUP Pg6of13
Amplitude(%)= 100
Pretrigger> Off
Afterburst> On
Select
Select
Select
WELD SETUP Pg6of13
Amplitude(%) 100
Pretrigger> Off
Afterburst> On
Select
Select
Select
