Chapter 6: Operation
Setting Other Weld Parameters
6-36 011-003-991 EN
If you chose Off, continue setting
other parameters in the menu.
If you chose On, use the Select keys
and the numeric keypad to enter the
values you want to use as Pretrigger
limits.
Use a Select key to choose one of
the following ways to begin the pre-
trigger ultrasonics:
Auto starts ultrasonics as the actua-
tor leaves its home position [1/8 in
(3.175 mm) minimum], and allows
access to enter Pretrg Amp(%) val-
ues.
Time allows you to select the per-
centage of maximum amplitude, and
Pretrg@T(s) values that will be used
for the pretrigger.
Press the Go Back/Esc key to exit
the submenu.
WELD SETUP Pg4of15
Amplitude(%) =100
Pretrigger> Off
Afterburst> Off
Select
Select
Select
PRETRIGGER Pg1of1
Off =Off
Auto =On
Time =Off
Select
Select
Select
