2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Other Weld Parameters
011-003-991 EN 6-47
Setting the Control Limits
You can select whether to use Control Limits. If you select ON, you will set limits of mini-
mum and maximum energy compensation (in Joules), a peak power cutoff (as a percent-
age of the maximum), an absolute distance (in) measured from the home position, or a
collapse distance (in) measured from the trigger. The 2000X uses these Control Limits in
addition to the primary weld mode and parameter to determine the end of the welding cycle
before moving to the Hold state.
When energy compensation is on and the minimum energy computed value is not
reached, the weld time will be extended up to 50% of the Set Weld time value in order to
reach this limit. When the maximum energy computed value is reached, the Weld Time will
be terminated and the Hold Time will start.
Take this action… To get this result…
Using the arrow keys, scroll downward
through the menu until you see Control
Limits. Press the Select key that corre-
sponds to Control Limits.
Press the same Select key again to toggle
between On and Off to turn the Control
Limits Off.
Press Enter on the numeric keypad to save
the new value, or press Go Back/Esc to
make no change to the value.
WELD SETUP Pg11of13
Frequency Offset>Off
Cycle Aborts> Off
Control Limits> Off
Select
Select
Select
WELD SETUP Pg11of13
Frequency Offset>Off
Cycle Aborts> Off
Control Limits> Off
Select
Select
Select
Enter
Go
Back/
Esc
