Chapter 6: Operation
Setting Other Weld Parameters
6-48 011-003-991 EN
If you chose Off, continue setting
other parameters in the menu.
If you chose On, use the Select keys
and the numeric keypad to enter the
values you want to use as Control
Limits.
Use the Select keys and the numeric
keypad to set the following limits to
end the weld portion of the cycle:
Pk Pwr Cutoff (%): set the peak
power cutoff as a percentage of the
maximum peak power.
Press the Go Back/Esc key to exit
the submenu.
WELD SETUP Pg11of13
Frequency Offset>Off
Cycle Aborts> Off
Control Limits> Off
Select
Select
Select
CNTL LIMITS Pg1of2
Pk Pwr Cut(%) =100
Select
Select
Select
