Setting Other Weld Parameters
6-50 011-003-991 EN
Setting the Suspect Limits
You can select whether to use Suspect Limits to indicate that a part might not have a good
weld. If you select ON, you can set limits of minimum and maximum time allowed for the
weld, energy levels (in Joules), peak power levels (as a percentage of the maximum), and/
or frequency (in Hz). If you set Reset Required to YES, when an alarm is generated, you
will need to press the Reset key prior to welding another part.
Take this action… To get this result…
Using the arrow keys, scroll downward
through the menu until you see Suspect
Limits. Press the Select key that corre-
sponds to Suspect Limits.
Press the same Select key again to toggle
between On and Off.
Press Enter on the numeric keypad to save
the new value, or press Go Back/Esc to
make no change to the value.
WELD SETUP Pg12of13
Cycle Aborts> Off
Control Limits> Off
Suspect Limits> On
Select
Select
Select
WELD SETUP Pg12of13
Cycle Aborts> Off
Control Limits> Off
Suspect Limits> On
Select
Select
Select
Enter
