Branson 2000X - Page 143

2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Other Weld Parameters
011-003-991 EN 6-51
If you chose Off, continue setting
other parameters in the menu.
If you chose On, use the Select keys and set
Reset Required to Yes or No.
Use the Select keys to set the suspect limits
for each of the following categories either
with a numeric value or to Off:
-/+Time(s): time (in seconds) above
and below the value you chose
-/+Energy(J): energy levels (in
Joules) above and below the value
you chose to be an acceptable weld.
-/+Pk Power(%): percentages of
peak power above and below the
value you chose to be an acceptable
weld.
Press the Go Back/Esc key to exit
the submenu.
WELD SETUP Pg12of14
Cycle Aborts> Off
Control Limits> Off
Suspect Limits > Off
Select
Select
Select
SUSP LIMITS Pg1of3
Reset Required =Yes
+S Time(s) =30.000
-S Time (s) =30.000
SUSP LIMITSPg2,3,of3
+S Energy (J) =65000
-S Energy (J) =65000
+S Pk Power(%) =100
-S Pk Power(%) = Off
Select
Select
Select
Go
Back/
Esc
