Chapter 6: Operation
Setting Other Weld Parameters
6-52 011-003-991 EN
Setting the Reject Limits
You can select whether to use Reject Limits to indicate that a part does not have a good
weld. You can set limits of minimum and maximum time for the weld (in seconds), energy
levels (in Joules), peak power levels (as a percentage of the maximum), and/or frequency
(in Hz). If you set Reset Required to YES, when an alarm is generated, you will need to
press the Reset key prior to welding another part.
Take this action… To get this result…
Using the arrow keys, scroll downward
through the menu until you see Reject
Limits. Press the Select key that corre-
sponds to Reject Limits.
Press the same Select key again to toggle
between On and Off.
Press Enter on the numeric keypad to save
the new value, or press Go Back/Esc to
make no change to the value.
WELD SETUP Pg14of15
Control Limits> Off
Suspect Limits> Off
Reject Limits> Off
Select
Select
Select
WELD SETUP Pg14of15
Control Limits> Off
Suspect Limits> Off
Reject Limits > Off
Select
Select
Select
Enter
