If you chose Off, continue setting
other parameters in the menu.
If you chose On, use the Select keys and set
Reset Required to Yes or No.
Use the Select keys to set the suspect limits
for each of the following categories either
with a numeric value or to Off:
-/+Time (s): times (in seconds)
above and below the value you
chose
-/+Energy(J): energy levels (in
Joules) above and below the value
you chose to be an acceptable or
suspect weld.
-/+Pk Power(%): percentages of
peak power above and below the
value you chose to be an acceptable
or suspect weld.
Press the Go Back/Esc key to exit
the submenu.
WELD SETUP Pg14of15
Control Limits> Off
Suspect Limits > Off
Reject Limits > Off
Select
Select
Select
REJ LIMITS Pg1of4
Reset Required =Yes
+R Time (s) =30.000
-R Time (s) =30.000
REJ LIMITS Pg2of4
+R Time (s) =30.000
-R Time (s) =30.000
+R Energy(J) =65000
REJ LIMITS Pg3and4of4
+R Energy (J) =Off
-R Energy (J) =Off
+R Pk Pwr =Off
-R Pk Pwr =Off
Select
Select
Select
Go
Back/
Esc
