Chapter 6: Operation
Using the System Configuration Menu
6-102 011-003-991 EN
Data String Sample Output
The following examples illustrate the data string that is sent out through the serial port after each weld. IDID
The table following these data strings shows the relationship between control levels. IDID can be any num-
ber from 1 to 9999. Table headings 1 through 4 respectively reference data string examples 1 through 4.
Sample Output for Control Level t with an ae actuator.
IDID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@sfff@aaaCRLF USCS units
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@sfff@aaaCRLF Metric units
Sample output for Control Level ea, d, or f with an ae actuator.
IDID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@ppp.p@eeeee@sfff@aaa@bbbCRLF
USCS units
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@ppp.p@eeeee@sfff@aaa@bbbCRLF
Metric units
Sample Output for Control Level d or f with an aed actuator.
IDID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@ppp.p@eeeee@w.wwww@z.zzzz@
x.xxxx@FFF@hhh@sfff@aaa@bbb@vv.vCRLF USCS units
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@ppp.p@eeeee@ww.www@zz.zzz@
xx.xxx@FFF@hhh@sfff@aaa@bbb@vv.vCRLF Metric units
Sample Output for Control Level f with an aef actuator.
IDID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@ppp.p@eeeee@w.wwww@z.zzzz@
x.xxxx@FFF@AAA@BBB@hhh@sfff@aaa@bbb@vv.vCRLF USCS units
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@ppp.p@eeeee@ww.www@zz.zzz@
xx.xxx@FFF@AAA@BBB@hhh@sfff@aaa@bbb@vv.vCRLF Metric units
Table 6.1 Code Output
1234 Where Definition
xxxxcccccccc@ is up to an 8-digit cycle count (Cycle Number)
xxxxhh:mm:ss@ is time of cycle in hours, minutes and seconds (Time)
xxxx
MM/DD/
YY@
is date in month, day and year (Date)
xxxxMode@ is weld mode (TIME, ENERGY, PKPWR, COL. ABS, G DET)
xxxxtt.ttt@ length of ultrasonics in seconds (Act. Time)
xxxppp.p@ is the peak power in percentage (Peak Power)
xxxeeeee@ is energy in joules (Act. Ener)
