2000X energy Power Supply Chapter 6: Operation
Instruction Manual Using the System Configuration Menu
011-003-991 EN 6-103
x x w.wwww@ is absolute distance at end of hold in inches or mm (Total Absolute)
x x z.zzzz@ is collapse at end of weld in inches or mm (Weld Collapse)
x x x.xxxx@ is collapse at end of hold in inches or mm (Total Collapse)
x x FFF@ is the trigger force in pounds or Newton’s (Trig. Force)
x AAA@ is set weld force or force A in pounds or Newton’s (Set Force A)
x BBB@ is set force B in pounds or Newton’s or N/A (Set Force B)
x x hhh@ is the weld force in pounds or Newton’s (Weld Force)
xxxxsfff@ is frequency change (Hz) from start of ultrasonics to end (Freq. Chg)
xxxxaaa@ is the set amplitude (or amplitude A) in percentage (Set AmpA)
xxxbbb@ is the set amplitude B in percentage or N/A (Set AmpB)
x x CRLF is the velocity in in/sec or mm/sec (Act. Vel)
xxxx@ is either a space, tab or comma as selected by user
xxxxIDID is a 4 digit # assigned by “welder Addr” in system configuration
Table 6.1 Code Output
