2000X energy Power Supply Chapter 6: Operation
Instruction Manual Using the System Configuration Menu
011-003-991 EN 6-121
Setting the Scale for Bar Graphs
Take this action… To get this result…
Press the Select key that corresponds to
Bar Graph Scales.
You will see the SCALES submenu. Press
the Select key that corresponds to Weld
Scale or Test Scale to set the scale for
those graphs.
If you selected Weld Scale from the
SCALES submenu, press the Select
key that corresponds to the Weld
Scale you want to use. Press the
Enter key on the numeric keypad
when you have set Weld Scale to
the value you want. You can only
select one value.
SYS CONFIG Pg17of19
Act Settings>
Amp Control =Int
Bargraph Scales>
Select
Select
Select
SCALES Pg1of1
Weld Scale> 1X
Test Scale> 1X
Select
Select
Select
WELD SCALE Pg1of1
1X =On
2X =Off
3X =Off
Select
Select
Select
