Branson 2000X - Page 255

2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-37
2000dt Abs S/R Limit
Cross
The minus reject absolute distance limit is equal to
or greater than the minus suspect absolute
distance limit.
Change the - reject absolute distance
limit or the - suspect absolute distance
limit through the Alarm Information
screen or Setup menu.
2000dt Abs S/R Limit
Cross
The plus reject
absolute distance limit is equal to or less than the
plus suspect absolute distance limit.
Change the +reject absolute distance or
+suspect absolute distance limit through
the Alarm Information screen or Setup
menu.
2000dt Amp Step Conflict The amplitude step at collapse value is equal to or
greater than the plus reject collapse limit.
Change the amplitude step or +reject
collapse distance limit through the Alarm
Information screen or Setup menu.
2000dt Amp Step Conflict The amplitude step at collapse value is equal to or
greater than the plus suspect collapse limit.
Change the amplitude step or +suspect
collapse distance limit through the Alarm
Information screen or Setup menu.
2000dt Amp Step Conflict The amplitude step at collapse value is equal to or
greater than collapse cutoff.
Change the amplitude step or collapse
cutoff through the Alarm Information
screen or Setup menu.
2000dt Amp Step Conflict The amplitude step at collapse distance is equal to
or greater than the collapse distance.
Change the amplitude step or collapse
distance through the Alarm Information
screen or Setup menu.
2000dt + - Col Limit
Crossed
The suspect limits for collapse distance that you
have entered are reversed.
Change the suspect collapse distance
limits through the Alarm Information
screen or Setup menu.
2000dt + - Col Limit
Crossed
The reject limits for
collapse distance that you have entered are
reversed.
Change the reject collapse distance limits
through the Alarm Information screen or
Setup menu.
2000dt Col S/R Limit Cross The plus reject
collapse distance limit is equal to or less than the
minus suspect collapse distance limit.
Change the +reject collapse distance
limit or - suspect collapse distance limit
through the Alarm Information screen or
Setup menu.
2000dt Col S/R Limit Cross The plus suspect
collapse distance limit is equal to or less than the
minus reject collapse distance limit.
Change the +suspect collapse distance
limit or - reject collapse distance limit
through the Alarm Information screen or
Setup menu.
2000dt Col S/R Limit Cross The plus reject collapse distance limit is equal to or
less than the plus suspect collapse
distance limit.
Change the +reject collapse distance
limit or +suspect collapse distance limit
through the Alarm Information screen or
Setup menu.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
