Chapter 7: Maintenance
System Alarm Tables
7-38 011-003-991 EN
2000dt Col S/R Limit Cross The minus reject
collapse distance limit is equal to or greater than
the minus suspect collapse distance limit.
Change the - reject collapse distance
limit or - suspect collapse distance limit
through the Alarm Information screen or
Setup menu.
2000dt Cutoff Conflict The minus reject
collapse limit is equal to or greater than the
collapse cutoff value.
Change the - reject collapse limit or
collapse cutoff through the Alarm
Information screen or Setup menu.
2000dt Cutoff Conflict The minus suspect collapse limit is equal to or
greater than the collapse cutoff value.
Change the - suspect collapse limit or
collapse cutoff through the Alarm
Information screen or Setup menu.
2000dt Cutoff Conflict The minus reject
absolute limit is equal to or greater than the
absolute cutoff value.
Change the - Reject absolute limit or
absolute cutoff through the Alarm
Information screen or Setup menu.
2000dt Cutoff Conflict The minus suspect absolute limit is equal to or
greater than the absolute cutoff value.
Change the - Suspect absolute limit or
absolute cutoff through the Alarm
Information screen or Setup menu.
2000dt + - F Limit Crossed The minus reject weld force limit is equal to or
greater than the plus reject weld force limit.
Change the - reject weld force limit and/
or the +reject weld force limit through the
Alarm Information screen or Setup menu.
2000dt + - F Limit Crossed The minus suspect force limit is equal to or greater
than the plus suspect force limit.
Change the - suspect weld force limit
and/or the +suspect weld force
limit.through the Alarm Information
screen or Setup menu.
+ - F Limit Crossed The + reject freq limit and - reject freq limit values
are crossed.
Either make the correction or run a horn
scan to automatically correct. This alarm
is valid for VGA only.
2000dt F S/R Limit Cross The plus reject force limit is equal to or less than
the minus suspect force limit.
Change the +reject force limit and/or the
- suspect force limit through the Alarm
Information screen or Setup menu.
2000dt F S/R Limit Cross The plus suspect force limit is equal to or less than
the minus reject force limit.
Change the +suspect force limit and/or
the - reject force limit through the Alarm
Information screen or Setup menu.
2000dt F S/R Limit Cross The plus reject force limit is equal to or less than
the plus suspect force limit.
Change the +reject force limit and/or the
+suspect force limit through the Alarm
Information screen or Setup menu.
2000dt F S/R Limit Cross The minus reject force limit is equal to or greater
than the minus suspect force limit.
Change the - reject force limit and/or the
- suspect force limit through the Alarm
Information screen or Setup menu.
Min Trigger Conflict The trigger force is set below the minimum
allowable value.
Minimum trigger force is canged after the
trigger force hs been set, or if
downloaded via host command.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
