2000X energy Power Supply Appendix E: Alarm Index
Instruction Manual
011-003-991 EN E - 1
Appendix E:Alarm Index
This alarm index is an alphabetical list of the alarms that appear on the system display and on printouts. In
some instances, the alarm display and alarm printouts (more complete) are slightly different, and therefore
are indexed separately as appropriate. In the on-line version of this document, all alarm page numbers are
hyper-linked to the full description, which describes the cause of the alarm condition and the steps to resolve
it.
- R Abs Dist Limit 7 - 26
– R Abs Dist Limit 7 - 24
- R Col Dist Limit 7 - 26
– R Energy Limit 7 - 25
- R Pk Power Limit 7 - 26
- R Time Limit 7 - 26
- R Trg > - R Abs 7 - 47
- R Trg > +R Abs 7 - 48
- R Trg > +S Abs 7 - 47
- R Trg > Abs 7 - 47
- R Trg >- R Abs 7 - 49
- R Trg Dist Limit 7 - 26
- R Weld Force Limit 7 - 26
- Reject Absolute Distance Limit 7 - 24, 7 - 26
- Reject Collapse Distance Limit 7 - 26
- Reject Energy Limit 7 - 25
- Reject Peak Power Limit 7 - 26
- Reject Time Limit 7 - 26
- Reject Trigger Distance Limit 7 - 26
- Reject Weld Force Limit 7 - 26
– S Abs Dist Limit 7 - 24
- S Col Dist Limit 7 - 27
– S Energy Limit 7 - 25
- S Pk Power Limit 7 - 26
- S Time Limit 7 - 27
- S Trg > - S Abs 7 - 48, 7 - 49
- S Trg > +S Abs 7 - 49
- S Trg > Abs 7 - 48
- S Trg Dist Limit 7 - 27
- S Weld Force Limit 7 - 27
- Suspect Absolute Distance Limit 7 - 24
- Suspect Collapse Dist Limit 7 - 27
- Suspect Energy Limit 7 - 25
- Suspect Peak Power Limit 7 - 26
- Suspect Time Limit 7 - 27
- Suspect Trigger Distance Limit 7 - 27
- Suspect Weld Force Limit 7 - 27
Symbols
+ - Abs Limit Crossed 7 - 40
+ - Col Limit Crossed 7 - 42
+ - F Limit Crossed 7 - 43
+ - Pwr Limit Crossed 7 - 35
+ - Time Limit Crossed 7 - 37
+ - Trg Limit Crossed 7 - 48
+- Eng Limit Crossed 7 - 30
+ R Col Dist Limit 7 - 21
+ R Pk Power Limit 7 - 25
+ Reject Absolute Distance Limit 7 - 24
+ Reject Collapse Distance Limit 7 - 21
+ Reject Energy Limit 7 - 25
+ Reject Peak Power Limit 7 - 25
+ S Col Dist Limit 7 - 21
+ S Trg Dist Limit 7 - 22
+ Suspect Absolute Distance Limit 7 - 24
+ Suspect Collapse Distance Limit 7 - 21
+ Suspect Energy Limit 7 - 25
+ Suspect Peak Power Limit 7 - 25
+ Suspect Trigger Distance Limit 7 - 22
+R Abs Dist Limit 7 - 22, 7 - 24
+R Energy Limit 7 - 22, 7 - 25
