2000X energy Power Supply Appendix E: Alarm Index
Instruction Manual
011-003-991 EN E- 3
Invalid Preset Error Code = 8 7 - 39
Invalid Preset Error Code = 9 7 - 39
M
Max Energy Reached 7 - 52
Max Timeout 7 - 15
Missing Part Abort 7 - 21
Missing Part Conflict 7 - 43, 7 - 44, 7 - 45, 7 - 46
N
No Amplitude Step 7 - 15
Collapse Distance for Amplitude Step not
Reached 7 - 16
Energy Value for Amplitude Step not Reached
7 - 16
External signal for Amplitude Step did not occur
7 - 15
Power level for Amplitude Step not Reached 7
- 15
No Force Step 7 - 34, 7 - 35
No message sent to printer 7 - 52
P
P/S NovRam 7 - 18
Peak Power Cutoff 7 - 16
Post Weld Seek (O/L) Overload 7 - 50
Power level for Amplitude Step not Reached 7 - 15
Power Supply NovRam Failed 7 - 18
Preset Data/BBR 7 - 18
Pressure > Weld Force 7 - 35
Pretrigger Conflict 7 - 46, 7 - 47
Pretrigger Overload 7 - 50
Pretrigger Timeout 7 - 18
Print Buffer 7 - 52
Printer Buffer Full 7 - 18
Printer Offline 7 - 18
Pwr S/R Limit Cross 7 - 35, 7 - 36
R
Rapid Trav. Conflict 7 - 36, 7 - 37
Recalibrate Actuator
Error Code = 100 7 - 18
Error Code = 1000 7 - 19
Error Code = 200 7 - 18
Error Code = 300 7 - 18
Error Code = 400 7 - 19
Error Code = 600 7 - 19
Error Code = 700 7 - 19
Error Code = 800 7 - 19
Error Code = 900 7 - 19
S
Seek Overload 7 - 51
Start Sw Time 7 - 19
Start Switch Closed (Failure) 7 - 19
Start Switch Stagger Time Missed 7 - 19
Start Switches Lost 7 - 20
Sys. Pres. Incorrect 7 - 37
T
Test Overload 7 - 51
The Actuator Type was changed since the last weld
cycle 7 - 17
Thermal Overload 7 - 20
Time Extended 7 - 52
Time S/R Limit Cross 7 - 37, 7 - 38
Time Value for Amplitude Step not Reached 7 - 15
Timeout Conflict 7 - 38
Trg > Weld Force 7 - 47
Trg Force Conflict 7 - 49
Trg S/R Limit Cross 7 - 48
Trig (Trigger) Before Pretrig 7 - 21
Trigger > Weld Force 7 - 16
Trigger is greater than the Weld Force 7 - 16
Trigger Lost during Hold 7 - 16
Trigger Lost during Weld 7 - 16
Trigger Lost in Hold 7 - 16
Trigger Lost in Weld 7 - 16
Trigger Timeout 7 - 21
U
Ultrasonics P/S 7 - 20
Ultrasonics Power Supply Not Present or Failed 7 -
20
Upper Limit Switch 7 - 20
Upper Limit Switch Failed 7 - 20
W
Weld Force > pressure 7 - 38
Weld O/L 7 - 50
Weld Overload 7 - 50
Weld Time was Extended for Energy Compensa-
tion 7 - 52
Wrong Actuator 7 - 20
Wrong Actuator AEF/AOF cannot be used with this
level control 7 - 20
