I-447
Index
I
Timing Verification 92, 138
Water Pressure Transducer 36, 45
Driveshaft
Bearing Housing, Seal Installation 386
Bearing Housing, Seal Removal 386
Installation 393
Removal 376, 399
Shimming 391
Special Removal Procedures 376
Dynamic Power Steering System (DPS)
Description 88, 301
DPS Module Service 307
DPS Module Software 308
DPS System Calibration 309
DPS Troubleshooting Tables 301
DPS-1 Description 301
DPS-2 Description 301
Electric Motor Service 322
Electrical Circuit Diagram 303
Ferrite Suppressor 306, 322
Manifold Assembly 320
Manifold Cleaning and Inspection 316
Manifold Disassembly 319
Manifold Filters 316
Manifold Installation 316
Manifold Removal 314
Manifold Service 314
Multiple Outboard Installations 311
Power Steering Assist Levels 45
Settings 45
Steering Position Sensor Calibration:
Multiple Engines
311
Single Engine 310
Steering Pressure Sensor:
Calibration
309
Ferrite Suppressor 322
Service 321
System Tests 304
Turn Limit Calibration 312
E
Electrical Circuits
EMM Pin Locations 112
Fuse 115
Ground Circuits 115
Ground Tests 115
Start Circuit 129
Electrical Harness
AMP Connectors 140
Connector Servicing 139
Deutsch Connectors 139
EMM J1-A Connector 112
EMM J1-B Connector 113
EMM J2 Connector 113
EMM J3 Connector 114
EMM J4 Connector 114
Packard Connectors 143
Pin Locations 112
Water Pressure Transducer Connection 36
Electronic Shift Controller
Description 86
Electronic Throttle Controller
Description 84
EMM
12 V Circuit Sensor 80
5 V Circuit Sensor 80
55 V Circuit Sensor 80
Connections 78
Diagnostics 90, 102
Fault Codes 91
Fuel Injector Servicing 94
Functions 78, 83
History and Reports 94
Inputs and Outputs Diagram 79
Pin Locations 112
Sensors 80, 81
Servicing 96
Software 95
Timing Verification 138
Engine Control Systems 80
Air Temperature Sensor 81
Barometric Pressure Sensor 80
Crankshaft Position Sensor 83
EMM Temperature Sensor 80
Engine Management Module (EMM) 78
Engine Temperature Sensor 81
Exhaust Pressure Sensor 81
ExhaustTemperature Sensor 81
Idle Controller 83
Knock Sensor 83
LOW Oil Level Switch 82
Oil Level Sensor 82
RPM Limiters 84
Engine Cover and Frames
Center Frame Installation 71
Center Frame Removal 67
