CASTLE EP User Manual

© AGRGS 2016 | Data subject to change without notice
67385867493098462 | en, eu, V5, 07. Oct 2016, page 14
4. Input interfaces:
● Two-level protection (resettable fuses and suppressor)
5. Output interfaces:
● All line protection from overload and overvoltage
(resettable fuses and suppressor)
Operating conditions
EP, PRO
ES, RS
Ambient temperature
0 to +45°C
-35 to +45°C
Relative humidity
Max 85% t°=30°C
Atmospheric pressure
84 106.7kPa
Interfaces
Communication line
EP, ES
PRO, RS
One standard Ethernet
port.
Baud rate 10 MB/s,
half-duplex.
Connection to the IP-
network through
active equipment.
One standard RS485 interface.
The length of a single network segment
up to 1,200 meters.
Number of controllers in the same
network segment up to 255.
Built-in switchable termination resistors
and biasing (lift) resistors.
Baud rate 78 Kbps.
Connecting readers
Up to 4 readers with the Wiegand-26 or Touch memory output
interface.
Connecting sensors
Up to 10 sensors with Open Collector (OC) or Dry Contact output
type.
Open Collector (OC) outputs
13 outputs.
Power relay outputs
4 relays; each relay contact group works for switching.
Connecting fire alarm
Two-wire line, galvanic isolated to connect multiple controllers to
a single loop of fire alarm. When triggered, alarm must provide a
break of a loop connected to controllers.
