Element
Use
CONF1
Dip-unit. Selects controller configuration.
CONF2
Dip-unit. Selects controller network address.
RT
Link terminator on jumper.
PA PB
Link biasing voltage (lift) on jumper.
K1
Switching relay 1 LED (NO1-COM1-NC1).
K2
Switching relay 2 LED (NO2-COM2-NC2).
K3
Switching relay 3 LED (NO3-COM3-NC3).
K4
Switching relay 4 LED (NO4-COM4-NC4).
PWR
Controller power supply status LED (green).
RX
RS485 data reception LED (yellow).
TX
RS485 data transmission LED (red).
DCD
Determine supply voltage type OFF jumper.
FD
Fire alarm input OFF jumper.
Table 2. Key elements of Pic 2
3.2 Controller package
No.
Position
Number
1
Controller in a metal housing
1 pc.
2
CD with this manual in electronic form
1 pc.
3
Warranty card with a date of sale mark
1 pc.
4
Diode 1N4007
2 pcs.
Table 3. Controller package
