● Gate control mode select Open, Close, Stop. Logic «B».
● Gate control impulse length set within 0.4 0.5 seconds.
● Max open/close time of gate sections set equal to about 1.1 times of the
opening (closing) time. E.g., if it opens fully within 5 seconds, then the parameter value
must be equal to 5.5 seconds.
● Max waiting time before autoclosing an opened gate is the waiting time for a vehicle
to start passing the gate after the drive is fully open. Set as desired.
● Gate sensor activation delay set within 0.5-2.0 seconds. This parameter is used to
ignore short-term when detecting passing vehicles with a trailer or other
parts that are transparent to the sensor.
● Other parameter values are not fundamental and may be left at their default values.
● After setting up, click OK. All the parameter values will be applied automatically.
10.8.3 Connecting FAAC 452MPS gate drives
To connect to the control panel of FAAC 452MPS gate drive, you need to switch the controller to
the third-party gate controller handling mode according to the logic defined in the Control
Program.
Toggle N
1
2
3
4
5
6
7
8
Toggle position
ON
ON
OFF
ON
X
X
OFF
OFF
Table 68. Settings of CONF1 dip-unit toggles for operating with FAAC 452MPS
The toggle selects the normal state of the control STOP button. ON normally closed,
OFF normally open. For the wiring diagram of the control panel, refer to Sec. 10.5 Connecting the
gate control panel.
The toggle selects the configuration of vehicle presence sensors. ON only one (the central) is
connected, OFF all three are connected (at the entrance, in the center and at the exit). For the
wiring diagram of vehicle presence sensors, refer to Sec. 10.6 Connecting vehicle presence sensors.
The programing micro toggle switches of FAAC 452MPS control unit should be set in the position
described in the following table.
Toggle N
1
2
3
4
5
6
7
8
9
10
11
12
Toggle position
ON
ON
OFF
ON
X
X
OFF
OFF
ON
ON
OFF
OFF
Table 69. Setting DS1 micro toggle switch on the FAAC 452MPS control unit board
Toggle N
1
2
3
4
Toggle position
X
X
OFF
X
Table 70. Setting DS2 micro toggle switch on the FAAC 452MPS control unit board
