● Set Time to open/close gate sections in direct gate control mode equal to about 1.1
times of the real opening (closing) time. E.g., if the gate opens fully within 10
seconds, then the parameter value must be equal to 11 seconds.
● Set Max waiting time before autoclosing an opened gate as desired.
● Delay between sector motors activation in direct gate control mode 0.00 second.
● Set Gate sensor activation delay within 0.5-2.0 seconds. This parameter is used to ignore
short-term when detecting passing vehicles with a trailer or other parts
that are transparent to the sensor.
● Other parameter values are not fundamental and may be left at their default values.
● After setting up, click OK. All the parameter values will be applied automatically.
10.10.5 Connecting drives with ZBK (ZBKE) control unit
To connect to a gate drive with ZBK (ZBKE) control unit, you need to switch the controller to the
third-party gate controller handling mode according to the logic defined in the Control Program.
Toggle N
1
2
3
4
5
6
7
8
Toggle position
ON
ON
OFF
ON
X
X
OFF
OFF
Table 88. Settings of CONF1 dip-unit toggles for operating with ZBK (ZBKE) control unit
The toggle selects the normal state of the control STOP button. ON normally closed,
OFF normally open. For the wiring diagram of the control panel, refer to Sec. 10.5 Connecting the
gate control panel.
The toggle selects the configuration of vehicle presence sensors. ON only one (the central) is
connected, OFF all three are connected (at the entrance, in the center and at the exit). For the
wiring diagram of vehicle presence sensors, refer to Sec. 10.6 Connecting vehicle presence sensors.
The function selection micro toggle switch on the ZBK (ZBKE) control unit board should be set in
the position described in the following table.
Toggle N
1
2
3
4
5
6
7
8
9
10
Toggle position
OFF
OFF
OFF
OFF
OFF
X
ON
ON
OFF
OFF
Table 89. Setting the micro toggle switch (1-10) for selecting functions on the ZBK (ZBKE) control unit board
Toggle N
11
12
13
14
15
16
17
18
19
20
Toggle position
X
X
OFF
X
X
X
X
OFF
OFF
OFF
Table 90. Setting the micro toggle switch (11-20) for selecting functions on the ZBK (ZBKE) control unit board
«X» sign in the "Toggle position" means that this switch performs the function that does not affect
the ACS operation, and it must be put in the required position according to the original instruction
for ZBK (ZBKE) control unit.
