EMF of self-induction that a
circuit can reach several hundred volts.
If there is no protective diode, an erosion of relay contacts occurs due to sparking
and it leads to a relay failure. And the use of a shared PSU for both the lock and the
controller will cause controller malfunctioning due to high voltage interference in
power supply lines.
Terminal
Use
COM2-NO2
The first door
COM2: The negative side -
NO2: The negative side - of the lock.
COM4-NO4
The second door
COM4: The negative side -
NO4: The negative side -
Table 15. Using the controller terminals for connecting electromechanical locks
Toggle
Use
5
ON using electromechanical lock for the first door.
6
ON using electromechanical lock for the second door.
Table 16. Setting CONF1 toggles for working with electromechanical locks
8.3.3 Connecting other types of locks
Other types of locks, e.g. those having separate inputs for Open/Close control, can also be
connected to the controller since two independent relays are used to control each lock. These
relays can work both in the potential and the pulse mode.
8.3.4 Example of connecting the lock with the separate control input
To work with SL-130 lock, the controller should be switched pulse control mode (for
the first door toggle of CONF1 dip-unit to be set in ON position, for the second door toggle
dip-unit to be set in ON position).
