● Function «Leave card» line for «Outside» direction (Return the card in OUT direction),
Door (access point) "1", Clamp (terminal) "O2, normally not active".
Switch to Port readers reassignment (Reader port reassignment) tab add the
string:
● Access point "1", Port reader type (reader port type) Extended for exit (Additional
for OUT direction), Port number "3".
Click OK and Apply.
Mode settings (Rules):
For visitor passes that have to be captured at the exit, on Main tab you have to create the mode
with the following settings:
● Affected Staff select all visitor passes.
● Affected doors (access points) select all access points blocking obj .
● On Special Rules tab enable Outside direction additional reader as card collector
(Allow passage in OUT direction only by additional card capture reader) option from the
drop-down menu.
Add a day or days according to working schedule and adjust them as necessary.
9.5.6 Connecting PERCo-IC03 card capture reader
To connect PERCo-IC03 CCR it is necessary to join controller terminals to CCR terminals.
Pic 36. Example of connecting PERCo-IC03 CCR in OUT direction
Access point settings:
