3=OFF normally closed
3=ON normally open
Selects normal state of the second door opening sensor. *
4=OFF normally closed
4=ON normally open
Selects a method for controlling the lock of the first door.
5=OFF potential (the lock is controlled by levels on one or two lines).
5=ON pulse (the lock is controlled by pulses on one or two lines).
Selects a method for controlling the lock of the second door.
6=OFF potential (the lock is controlled by levels on one or two lines).
6=ON pulse (the lock is controlled by pulses on one or two lines).
N/A, must be in OFF position.
Table 10. Sample settings of CONF1 dip-unit toggles in Two Door configuration
Notes:
* The normal state of the opening sensor is its state when the door is closed. E.g., the most common
sensors reed switches have the normally closed state.
The description of the door lock control logic is provided in Sec. 11.7 The operating logic in Two
Door configuration.
8.2 Connecting readers for doors
Readers are connected to controller terminals according to Sec. 6.3. Connecting readers and
contactors. Overview.
Reader for OUT direction of the first door
Reader for IN direction of the first door
Reader for OUT direction of the second door
Reader for IN direction of the second door
Table 11. Reader assignments when working in Two Door configuration
8.3 Connecting door locks. Overview
Locks are managed by four relays located on the controller board (K1-K4).
