Toggles rmine the basic configuration: Doors, Turnstiles, Gates, or Registration
Board. Toggles -8 determine its optional parameters.
CONF2 dip-unit is designed for setting the RS485-controller network address (see 6.4.4 Setting
RS485 network address).
All the settings specified by dip-toggles come into effect at the If you change
toggle positions on the working controller, it will not take effect until the controller is rebooted.
To fine-tune the controller for a specific turnstile, lock, or sensor, you should carefully read this
instruction sections dedicated to a particular device and review examples of connecting to the
equipment.
6.2 Controller power supply
The controller is powered by DC voltage 9.9 17.8V, the max current consumption of the controller
is 160mA.
● If the only controller is powered by a PSU, another PSU must be installed in any
convenient location between the nearest supply panel and the controller. This PSU must
provide the output DC voltage of 12V and a current of 200mA.
● If a single PSU powers the controller and other devices, such as readers, locks and other
peripherals, it is necessary to provide load capacity of a PSU sufficient to supply all
connected devices with a current reserve of about 20%. Power supply reserve is required
for the correct operation of the controller in abnormal situations, such as short circuit in
communication links, power supply chain, etc.
In case of emergency, integrated controller protection circuits cut off power supply of overloaded
or closed line, nevertheless the current consumption from the power supply can be increased for a
short time during protection activation.
E.g., short-circuiting reader power line causes the 500mA fuse to trip. At the same time, the current
consumption can briefly rise to 1A.
Among UPS (uninterruptable power supply units) array, some models can be suggested, e.g. "BBP",
"Skat", "BRP", and "RIP".
Do not use ACCORDTEC PSU with Matrix-II EH readers. This bundle might work in
the most arbitrary manner, ranging from complete failure to delays or omissions of
certain cards. Diagnosis is simple: connect the battery instead of BBP-20 UPS to
start everything working immediately.
The controller immediately responds to an access request (reading a card, pressing
a button, etc.). This property does not depend on the number of controllers in the
system, communication quality, number of personnel, and link range.
After PSU installation, a ~220V single-phase power should be connected to it.
