2. To the controller. Passages authorized by pressing buttons will be recorded in the ACS
exactly as a "Passage authorized by pressing button", but there will be no way to
enable free passage mode.
The control panel operating logic is described in Sec. 11.8.2 Working with the turnstile control
panel.
9.7 Connecting OMA turnstiles
In this section, you can find wiring diagrams for OMA turnstiles with OMA 264MS1, OMA-DD.958,
OMA 957, and OMA 956-1/2/3/4 control units (controllers).
9.7.1 Connecting OMA turnstiles. Overview
For operating with OMA turnstiles, the controller should be switched to the potential control mode
for controlling the turnstile and for working with normally closed passage sensors according to
Simplified scheme.
In the Control Program, go to the controller settings and enable the additional option (on Doors
tab, select the access point, click Settings, uncheck Show only basic settings box, check Activate
OMA turnstile specific workaround, and click OK).
Table 36. Settings of CONF1 dip-unit toggles for operating with OMA turnstiles
OMA turnstiles come with different models of built-in controllers.
1. OMA-DD.958 control unit (used in OMA-26.46,
OMA-26.56, and OMA-26.76 tripod
turnstiles; and also in OMA-16.68 OMA-18.68 full height turnstiles).
2. OMA 957 control unit (used in OMA-26.46 tripod turnstiles).
3. OMA 956-1/2/3 (discontinued) and OMA 956-4 (used in all types of turnstiles) control
units.
The connection circuit depends on the type of embedded turnstile controller.
Connecting the controller must be made directly to OMA turnstile controller
terminals, and not to its system control panel terminals, as recommended in the
turnstile manual.
