4. Controller specifications
Physical characteristics
Metal housing dimensions
240 * 260 * 57 mm
Electrical characteristics
Supply voltage
+9.9 ... 17.8V
Current consumption
Max 160mA
Power consumption
Max 3W
Power line tripping voltage
18V
Power relay output switching voltage limit
125V
Power relay output switching current limit
12A
OC type output switching voltage limit
30V
OC type output switching current limit
0.1A
Controller built-in
circuit protection
1. Power supply:
● Overvoltage and reverse polarity protection (suppressor)
● Overload protection (resettable fuse)
● Independent overload protection for all reader power
supply chains (resettable fuses)
2. Communication line (Ethernet):
● Full galvanic isolation
3. Communication line (RS485):
● Full galvanic isolation (voltage up to 2500V)
● Built-in four-level lightning protection
● Gas-filled surge arrester (single release suppressing
current 15.000A, periodic noise suppressing current
10A)
● Suppressors (voltage limitation at +12... -7V)
● Resettable fuses for protection against overloads and
short circuits in the communication line
● Resettable fuses for interface circuit supply
