9.13 Connecting Tornello turnstiles
For operating with Tornello Vento and Epico turnstiles, the controller should be switched to the
pulse control mode for controlling the turnstile and for working with normally open passage
sensors according to Simplified scheme.
Max waiting time before autolocking an unlocked turnstile option should be
set within 5 to 5.5 seconds range.
Table 49. Settings of CONF1 dip-unit toggles for operating with Tornello turnstiles
Because o -shut-off passage timer and a non-standard control
panel design), there are certain restrictions on its operation as part of ACS:
● The control panel connection is performed only to the turnstile control unit directly. All
the passages authorized from the control panel will be recorded in the ACS as the break-
ins.
● No constant turnstile unlock mode from the ACS client.
● Some conflict situations are likely to arise, when a passage by a card and pressing control
panel buttons occur simultaneously.
Pic 77. Connecting Tornello turnstiles
