The rest of the unit terminals, excluding photocells (mains, electric motor, limit switches) are
connected according to the original instruction for Control 144N control unit.
S20 and S20a dip-switches on the Control 144N control unit board should be set in ON position.
All vehicle presence sensors, as well as manual control panel, should be connected
exclusively to the controller, and not to the barrier drive or to both of them.
Violation of this requirement may lead to different conflicts ranging from passage
registration failure to "freezing" the barrier beam in the intermediate states to
eventual damage of a passing vehicle.
-in radio receiver is forbidden. Command submission
bypassing the ACS controller will sooner or later lead to a damage of a passing
vehicle. For controlling the drive via remote keys, you should use Wiegand
interface radio receivers connected to the ACS controller.
Before enabling the access, you need to make its mandatory settings.
To do this, run Control Program select Doors tab select the desired controller from the list
click Settings uncheck Show only basic settings. Then make the following settings:
● Gate control mode select Straight drive direction (Direct drive control) from the drop-
down menu.
● Set Time to open/close gate sections in direct gate control mode equal to about 1.1
seconds, then the parameter value must be equal to 11 seconds.
● Max waiting time before autoclosing an opened gate is the waiting time for a vehicle
to start passing the barrier after the drive is fully open. Set as desired.
● Delay between sector motors activation in direct gate control mode 0.00 second.
● Gate sensor activation delay set within 0.5-2.0 seconds. This parameter is used to
ignore short-term when detecting passing vehicles with a trailer or other
parts that are transparent to the sensor.
● Other parameter values are not fundamental and may be left at their default values.
● After setting up, click OK. All the parameter values will be applied automatically.
10.18.3 Connecting DoorHan SHAFT-30 drives
To connect to SHAFT-30 control unit, you need to switch the controller to the third-party gate
controller handling mode according to the logic defined in the Control Program.
Table 117. Settings of CONF1 dip-unit toggles for operating with the SHAFT-30
