Test Pattern : Not Configured, Status : not running, Sync Detected : 0
Interval : 1 minute(s), Time Remain : 0 (ms)
Bit Errors (since BERT started): 0 bits,
Bits Received (since BERT started): 0 Kbits
Bit Errors (since last sync): 0 bits
Bits Received (since last sync): 0 Kbits
Table 60: show controllers t1 brief Field Descriptions
DescriptionField
T1 channel is operating. The channel state can be up,
down, or administratively down. Loopback conditions
are shown by (Locally Looped) or (Remotely
Looped).
T1 0/4/2/0/1 is up
Mode of the T1 controller, which can be ATM.mode
DS0 time slots assigned to the T1 channel.timeslots
Performance monitoring is through Facility Data Link
based on ANSI T1.403 specification or AT&T
standard specification number 54016.
FDL per spec-name spec.
Any alarms detected by the T1 controller are
displayed here. Possible alarms are as follows:
•
Transmitter is sending remote alarm.
•
Transmitter is sending AIS.
•
Receiver has loss of signal.
•
Receiver is getting AIS.
•
Receiver has loss of frame.
•
Receiver has remote alarm.
•
Receiver has no alarms.
Receiver has no alarms.
Framing type on the channelized controller. Values
are ESF and SF.
Framing
Line coding format on the channelized controller.
Values are AMI or B8ZS.
Line Code
Clock source on the T1 channel. Values are internal
and line.
Clock Source
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
1048
T3, E3, T1, E1 Controller Commands on the Cisco ASR 9000 Series Router
show controllers t1
