The dot1q vlan command is is replaced by the encapsulation dot1q command. It is still available for
backward-compatibility, but only for Layer 3 interfaces. The encapsulation dot1q command must be
used going forward.
Note
Task ID
OperationsTask ID
read, writevlan
Examples
This example shows how to configure the VLAN ID and IP address on a subinterface:
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)# interface TenGigE 0/2/0/4.1
RP/0/RSP0/CPU0:router(config-subif)# dot1q vlan 10
RP/0/RSP0/CPU0:router(config-subif)# ipv4 addr 10.0.0.1/24
This example shows how to configure the VLAN IDs for both VLANS in a single Q-in-Q attachment circuit
(AC). In this case, incoming traffic must match both of the VLAN IDs before it is accepted by the subinterface:
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)# interface TenGigE 0/2/0/4.1
RP/0/RSP0/CPU0:router(config-subif)# dot1q vlan 10 20
This example shows how to configure the VLAN IDs for a Q-in-any AC. In this case, all incoming traffic
must have two VLAN tags, where the outer VLAN ID matches the configured value, while the inner VLAN
ID can be any value.
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)# interface TenGigE 0/2/0/4.1 l2transport
RP/0/RSP0/CPU0:router(config-subif)# dot1q vlan 10 any
Related Commands
DescriptionCommand
Displays statistics for all interfaces configured on the router or for
a specific node.
show interfaces, on page 516
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
1091
VLAN Subinterface Commandsonthe Cisco ASR 9000 Series Router
dot1q vlan
