module: Module number. A physical layer interface module (PLIM) is always 0.
◦
instance: Number of the controller instance. The instance is always 0.
•
If specifying a virtual interface, the number range varies, depending on interface type.
Task ID
OperationsTask ID
readinterface
Examples
The following example shows how to display information for a management multilink controller:
RP/0/RSP0/CPU0:router# show controllers mgmtmultilink 0/3/0/0 all
Controller MgmtMultilink0/3/0/0
State is up
Number of bundles: 2
Bundle 1 - Multilink0/3/0/0/1 (0x06186240)
Type: Full Framed T1s
Bandwidth: 3072 kbps
Encapsulation: Frame Relay
Fragment size: 0
Number of members: 2
Ancestor name: SONET0/3/0/0
Member(s):
Serial0/3/0/0/1/1:0 (0x0619b640) Active
Serial0/3/0/0/1/2:0 (0x06176980) Active
Bundle 2 - Multilink0/3/0/0/2 (0x06176840)
Type: Full Framed T1s
Bandwidth: 3072 kbps
Encapsulation: Frame Relay
Fragment size: 0
Number of members: 2
Ancestor name: SONET0/3/0/0
Member(s):
Serial0/3/0/0/1/3:0 (0x0619b3c0) Active
Serial0/3/0/0/1/4:0 (0x0618b9c0) Active
RP/0/RSP0/CPU0:router# show controllers mgmtmultilink 0/3/0/0 brief
MgmtMultilink0/3/0/0 is up
RP/0/RSP0/CPU0:router# show controllers mgmtmultilink 0/3/0/0 tabular
MgmtMultilink0/3/0/0 is up
RP/0/RSP0/CPU0:router# show controllers mgmtmultilink 0/3/0/0 internal-state
Interface(layer) admin_up if_state
--------------------- -------- --------
MgmtMultilink0/3/0/0 up up
RP/0/RSP0/CPU0:router# show controllers mgmtmultilink 0/2/0/0
Controller MgmtMultilink0/2/0/0
State is up
Number of bundles: 1
Bundle 1 - Multilink0/2/0/0/1 (0x0802e400)
Type: Full Framed T1s
Bandwidth: 1536 kbps
Encapsulation: PPP
Fragment size: 0
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
688
Multilink Commands on the Cisco ASR 9000 Series Router
show controllers mgmtmultilink
