If specifying a virtual interface, the number range varies, depending on interface type.
Use the show controllers sonet command to display information about the operational status of SONET
layers on a particular SONET port.
If the manageability PIE is not installed, you can use the show controllers sonet command to display the
counters for the current 15 minutes only without history data. However, the SONET MIB is still available but
is limited to the current bucket of data. History data is still available only when the manageability PIE is
loaded. The show controllers sonet command is available at any time to display current data, and history
data is stored in the line card rather in the history bucket.
Task ID
OperationsTask ID
readinterface
Examples
The following is sample output from the show controllers sonet command:
RP/0/RSP0/CPU0:router# show controllers sonet 0/1/2/1
Port SONET0/1/2/1:
Status: Up
Loopback: None
SECTION
LOF = 0 LOS = 0 BIP(B1) = 0
LINE
AIS = 0 RDI = 1 FEBE = 0 BIP(B2) = 0
PATH
AIS = 0 RDI = 0 FEBE = 0 BIP(B3) = 0
LOP = 0 NEWPTR = 0 PSE = 0 NSE = 0
PLM = 0 TIM = 0
Line delays trigger: 0 ms clear: 10000 ms
Path delays trigger: 0 ms clear: 10000 ms
Last clearing of "show controllers SONET" counters never
Detected Alarms: None
Asserted Alarms: None
Mask for Detected->Asserted: None
Detected Alerts: None
Reported Alerts: None
Mask for Detected->Reported: None
Alarm reporting enabled for: SLOS SLOF SF_BER PLOP
Alert reporting enabled for: B1-TCA B2-TCA B3-TCA
Framing: SONET
SPE Scrambling: Enabled
C2 State: Stable C2_rx = 0x16 (22) C2_tx = 0x16 (22) / Scrambling Derived
S1S0(tx): 0x0 S1S0(rx): 0x0 / Framing Derived
PATH TRACE BUFFER : STABLE
Remote hostname : P1_CRS-8
Remote interface: POS0/1/4/0
Remote IP addr : 0.0.0.0
APS
No APS Group Configured
Protect Channel 0 DISABLED
Rx(K1/K2) : 0x00/0x00
Tx(K1/K2) : 0x00/0x00
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
907
SONET Controller Commands on the Cisco ASR 9000 Series Router
show controllers sonet
