DescriptionField
Two S bits received in the last H1 byte.S1S0(tx)
SONET path trace buffer is used to communicate
information regarding the remote hostname, interface
name/number, and IP address. This use of the J1 (path
trace) byte is proprietary to Cisco.
PATH TRACE BUFFER
Name of the remote host.Remote hostname
Interface of the remote host.Remote interface
IP address of the remote host.Remote IP addr
Configuration status of the APS featureAPS
Indicates whether or not an APS group is configured.APS Group
Indicates whether or not channel 0 is protected.Protect Channel 0
Contents of the received and transmitted K1 and K2
bytes at the local end in an APS configuration.
Rx(K1/K2)/Tx(K1/K2)
Contents of the received and transmitted K1 and K2
bytes at the remote end in an APS configuration.
Remote Rx(K1/K2)/Tx(K1/K2)
List of the bit error rate (BER) thresholds you
configured with the threshold (SONET) command.
BER thresholds
List of threshold crossing alarms (TCA) you
configured with the threshold (SONET) command.
TCA thresholds
Type of small form-factor pluggable (SFP) used in
the associated port.
Optics type
Measured laser bias current, in milliamps (mA). The
valid range is 0 through 131 mA.
Tx laser current bias
Actual and configured clock source.Clock source
Power status of the SONET controller.Optical Power Monitoring
Current information, in milliamps (mA), in the
transmit direction.
Tx laser current bias
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
911
SONET Controller Commands on the Cisco ASR 9000 Series Router
show controllers sonet
