CONSOLE AI | Managing Channels (CP2) | 248
Option Description
Threshold Determines the RMS level at which the compressor begins to operate.
The range is from -30 to +20dBu. The defaultis 0dBu.
Attack Sets the time increment used to reduce the signal from input level to
the prescribed output level when the thresholdis exceeded. The range
is 0 to 100ms in .5ms steps. The default is 10ms.
Ratio Changes the rate of compression applied to the input signal as the
signal exceeds the threshold level. The range is1:1 to 1:20dB. The
default is 1:1.
Release Sets the time increment used to restore the signal to the input level
when the signal drops below the threshold. Therange is 100ms to 2
seconds, in 5ms increments. The default is 500ms.
Note:
The graph reflects the input/output decibel levels with the gain, ratio, and threshold settings you
select.
18.Click Close.
Mute
19.To mute this channel, click the Mute button (the button changes to red if the channel is muted).
Gain
20.You can change the gain in any of the following ways:
• Drag the slider
• Type a value in the text box
• Click the incrementer and decrementer arrows beside the text box to set the value
Feedback Eliminator
21.To enable or disable Feedback Eliminator, click the Feedback button.
The Feedback Eliminator dialog box appears:
Note:
To set up Feedback Eliminator, you must be in online mode (connected to a device or stack).
See Online Mode vs. Offline Mode for more information.
