• PIR (64Kbps) – Specifies the Peak Information Rate of the packet. Tha range is from 0
to 15624. The unit is 64Kbps. That is to say, 1 means 64Kbps.
• CBS (Kbyte) – Specifies the Committed Burst Size of the packet. Tha range is from 0 to
16384. The unit is Kbyte. That is to say, 1 means 1Kbyte. This parameter is optional and
the default value is 4*1024. The max value is 16*1024.
• PBS ( Kbyte) – Specifies the Peak Burst Size of the packet. Tha range is from 0 to
16384.The unit is Kbyte. That is to say, 1 means 1Kbyte. This parameter is optional and
the default value is 4*1024. The max value is 16*1024.
srTCM – Single Rate Three Color Marker, marks packets green, yellow or red based on a rate
and two burst sizes. This is useful when only burst size matters.
• CIR (64Kbps) – Specifies the Committed Information Rate of the packet. Tha range is
from 0 to 15624. The unit is 64Kbps. That is to say, 1 means 64Kbps.
• CBS (Kbyte) – Specifies the Committed Burst Size of the packet. Tha range is from 0 to
16384. The unit is Kbyte. That is to say, 1 means 1Kbyte. This parameter is optional and
the default value is 4*1024. The max value is 16*1024.
• EBS (K byte) – Specifies the Excess Burst Size of the packet. Tha range is from 0 to
16384. The unit is Kbyte. That is to say, 1 means 1Kbyte. The maximum value is
16*1024.
Action Conform – Specifies the action when the packet is in “green color” mode.
• Replace dscp – Change the dscp of the packet.
• Counter - Specifies the counter. This is optional. The default is Disabled.
Exceed – Specifies the action when the packet is in “yellow color” mode.
• Permit – Permits the packet.
• Replace DSCP – Allows you to change the DSCP of the packet.
• Drop – Drops the packet.
• Counter - Specifies the counter. This is optional. The default is Disabled.
Violate – Specifies the action when the packet is in “red color” mode.
• Permit – Permits the packet.
• Replace DSCP – Change the DSCP of the packet.
• Drop – Drops the packet.
• Counter - Specifies the counter. This is optional. The default is Disabled.
Click Apply to implement changes made, click Back to return to the ACL Flow Meter.
