xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
1010
Example
To configure VRRP:
DGS-3420-28SC:admin#config vrrp vrid 1 ipif System state enable
Command: config vrrp vrid 1 ipif System state enable
Success.
DGS-3420-28SC:admin#
30-5 config vrrp ipif
Description
This command is used to configure a virtual router authentication type on an interface.
Format
config vrrp ipif <ipif_name 12> [authtype [none | simple authdata <string 8> | ip authdata
<string 16>]]
Parameters
ipif - Specify the name of IP interface used for this configuration.
<ipif_name 12> - Enter the IP interface name used here. This name can be up to 12 characters
long.
authtype - Specify the VRRP’s authentication type.
none - Specify that no authentication algorithm will be used on this interface.
simple - Specify that the authentication algorithm will be set to simple text on this interface.
authdata - Specify the authentication data used in the simple text authentication algorithm.
<string 8> - Enter the authentication data used in the simple text authentication algorithm
here. This value can be up to 8 characters long.
ip - Specify that the authentication algorithm will be set to IP authentication header on this
interface.
authdata - Specify the authentication data used in the IP authentication header algorithm.
<string 16> - Enter the authentication data used in the IP authentication header algorithm
here. This value can be up to 16 characters long.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure a VRRP IP interface:
