xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
1109
Appendix D
RADIUS Attributes
Assignment
The RADIUS Attributes Assignment on the Switch is used in the following modules: 802.1X (Port-
based and Host-based), Japanese Web-based Access Control, Web-based Access Control, and
MAC-based Access Control.
The description that follows explains the following RADIUS Attributes Assignment types:
1. Ingress/Egress Bandwidth
2. 802.1p Default Priority
3. VLAN
4. ACL
To assign Ingress/Egress bandwidth by RADIUS Server, the proper parameters should be
configured on the RADIUS Server. The tables below show the parameters for bandwidth.
The parameters of the Vendor-Specific attributes are:
Vendor-Specific Attribute Description Value Usage
Vendor-ID Defines the vendor. 171 (DLINK) Required
Vendor-Type Defines the attribute. 2 (for ingress
bandwidth)
3 (for egress
bandwidth)
Required
Attribute-Specific Field Used to assign the bandwidth
of a port.
Unit (Kbits) Required
If the user has configured the bandwidth attribute of the RADIUS server (for example, ingress
bandwidth 1000Kbps) and the 802.1X authentication is successful, the device will assign the
bandwidth (according to the RADIUS server) to the port. However, if the user does not configure the
bandwidth attribute and authenticates successfully, the device will not assign any bandwidth to the
port.
If the bandwidth attribute is configured on the RADIUS server with a value of “0”, the effective
bandwidth will be set to “no_limited”.
If the bandwidth attribute is configured to be less than “0” or greater than the maximum supported
value, the effective bandwidth will be ignored.
