xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
1029
Command: config vlan vlanid default advertisement enable
Success.
DGS-3420-28SC:admin#
32-7 config port_vlan
Description
This command is used to set the ingress checking status and the sending and receiving of GVRP
information.
Format
config port_vlan [<portlist> | all] {gvrp_state [enable | disable] | ingress_checking [enable |
disable] | acceptable_frame [tagged_only | admit_all] | pvid <vlanid 1- 4094>} (1)
Parameters
<portlist> - Specify a range of ports to be set.
all - Specify to make all ports to be set.
gvrp_state - Specify if the port is allowed to dynamically become a member of a VLAN when
receiving GVRP.
enable - Enable GVRP for the ports specified in the port list.
disable - Disable GVRP for the ports specified in the port list.
ingress_checking - When ingress checking is enabled, the Switch checks if the incoming packet
was assigned a VLAN on which the ingress port is a VLAN member. If the incoming packet and
the ingress port are not in the same VLAN, the packet will be dropped.
enable - Enable ingress checking for the specified port list.
disable - Disable ingress checking for the specified port list.
acceptable_frame - Specify the type of frame that will be accepted by the port.
tagged_only - Only tagged frame will be received.
admit_all - Both tagged and untagged frames will be accepted.
pvid - Specify the Port VID (PVID) that will be associated with the port.
<vlanid 1- 4094> - Specify the VLAN ID between 1 and 4094.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the port VLAN:
DGS-3420-28SC:admin#config port_vlan 1-5 gvrp_state enable ingress_checking enable
acceptable_frame tagged_only pvid 2
Command: config port_vlan 1-5 gvrp_state enable ingress_checking enable
acceptable_frame tagged_only pvid 2
Success.
