xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

1040

32-20 show pvid auto_assign

Description

This command is used to display the PVID auto-assign state.

Format

show pvid auto_assign

Parameters

None.

Restrictions

None.

Example

To display the PVID auto-assignment state:

DGS-3420-28SC:admin#show pvid auto_assign

PVID Auto-assignment: Enabled.

DGS-3420-28SC:admin#
