xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

1064

Restrictions

Only Administrator, Operator and Power-User level users can issue this command.

Example

To config the profile 2 to drop all type and all color packets:

DGS-3420-28SC:admin#config wred profile profile_id 2 min_threshold 30

max_threshold 50 max_drop_rate 10

Command: config wred profile profile_id 2 min_threshold 30 max_threshold 50

max_drop_rate 10

Success.

DGS-3420-28SC:admin#

35-5 config wred ports

Description

This command is used to configure the WRED parameters of the ports.

Format

config wred ports [<portlist> | all] [cos <class_id 0-7> [profile [default | profile_id <int 2-128> |

<profile_name 32>] | weight <int 0-15>] | profile [default | profile_id <int 2-128> | <profile_name

32>] | weight <int 0-15>]

Parameters

<portlist> - Specify a range of ports to be configured.

all - Specify all ports to be configured.

cos – Specify the hardware priority queues.

<class_id 0-7> - Enter the priority between 0 and 7.

profile - Specify the profile to be used.

default - Specify the default profile to be used.

profile_id - Specify the profile ID to be used.

<int 2-128> - Enter the profile ID between 2 and 128.

<profile_name 32> - Specify the profile name to be used.

weight – Specify the weight of average queue size formular.

<int 0-15> - Enter the weight between 0 and 15.
