xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
107
udp - Specify that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Specify the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Specify the TCP destination port mask.
protocol_id_mask - Specify that the rule applies to the IP protocol ID traffic.
<hex 0x0-0xff> - Specify that the rule applies to the IP protocol ID traffic.
user_define_mask - (Optional) Specify the L4 part mask.
<hex 0x0-0xffffffff> - Specify the L4 part mask.
packet_content_mask - A maximum of six offsets can be specified. Each offset defines one byte
of data which is identified as a single UDF field. The offset reference is also configurable. It
can be defined to start at the end of the tag, the end of the Ethernet type, or the end of the IP
header.
offset_chunk_1 - Specifies the offset chunk 1 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 1 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 1 mask value here.
offset_chunk_2 - Specifies the offset chunk 2 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 2 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 2 mask value here.
offset_chunk_3 - Specifies the offset chunk 3 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 3 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 3 mask value here.
offset_chunk_4 - Specifies the offset chunk 4 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 4 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 4 mask value here.
ipv6 - Specify the IPv6 filtering mask.
class - Specify the IPv6 class mask.
flowlabel - Specify the IPv6 flow label mask.
source_ipv6_mask - Specify the IPv6 source IP mask.
<ipv6mask> - Specify the IPv6 source IP mask.
destination_ipv6_mask - Specify the IPv6 destination IP mask.
<ipv6mask> - Specify the IPv6 destination IP mask.
tcp - Specify that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Specify the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Specify the TCP destination port mask.
udp - Specify that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Specify the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Specify the TCP destination port mask.
icmp - Specify that the rule applies to ICMP traffic.
type - (Optional) Specify the ICMP packet type.
code - (Optional) Specify the ICMP code.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
