xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
148
<value 0-63> - Enter the DSCP replace value here. This value must be between 0 and 63.
drop - Drops the packet.
counter - (Optional) Specifies the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared when
the function is disabled.
enable - Specifies that the ACL counter parameter will be enabled.
disable - Specifies that the ACL counter parameter will be disabled.
violate - Specify the action when packet is in “red color”.
permit - Permit the packet.
replace_dscp - (Optional) Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0 and 63.
drop - Drops the packet.
counter - (Optional) Specifies the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared when
the function is disabled.
enable - Specifies that the ACL counter parameter will be enabled.
disable - Specifies that the ACL counter parameter will be disabled.
delete - Delete the specified “flow_meter”.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure a “two rates three color” flow meter:
DGS-3420-28SC:admin# config egress_flow_meter profile_id 1 access_id 1 tr_tcm cir
1000 cbs 200 pir 2000 pbs 200 exceed permit replace_dscp 21 violate drop
Command: config egress_flow_meter profile_id 1 access_id 1 tr_tcm cir 1000 cbs 200
pir 2000 pbs 200 exceed permit replace_dscp 21 violate drop
Success.
DGS-3420-28SC:admin#
6-7 show egress_flow_meter
Description
This command is used to display the egress flow-based metering configuration.
Format
show egress_flow_meter {[profile_id <value 1-4> | profile_name <name 1-32>] {access_id
<value1-128>}}
Parameters
profile_id - (Optional) Specifies the index of access list profile.
<value 1-4> - Enter the profile ID used here. This value must be between 1 and 4.
