xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
215
<int 1-8191> - Specify the MEP MEPID between 1 and 8191.
period - (Optional) Specifies the transmitting interval of the LCK PDU.
1sec - Specifies that the transmitting interval period will be set to 1 second.
1min - Specifies that the transmitting interval period will be set to 1 minute.
level - (Optional) Specifies the client level ID to which the MEP sends LCK PDU. The default
client MD level is the MD level that the most immediate client layer MIPs and MEPs exist on.
<int 0-7> - Enter the client level ID used here. This value must be between 0 and 7.
state - (Optional) Specifies the LCK function state used.
enable - Specifies that LCK function state will be enabled.
disable - Specifies that LCK function state will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the LCK function state as enabled and specify a client level of 5:
DGS-3420-28SC:admin# config cfm lock md op-domain ma op-ma mepid 1 state enable
level 5
Command: config cfm lock md op-domain ma op-ma mepid 1 state enable level 5
Success.
14-30 config cfm trap
Description
This command is used to configure the state of the CFM trap.
Format
config cfm trap [ais | lock] state [enable | disable]
Parameters
ais - Specify the AIS trap status to be configured. If the trap status of AIS is enabled, a trap will
be sent out when an ETH-AIS event occurs or clears.
lock - Specify the LCK trap status that to be configured. If the trap status of LCK is enabled, a
trap will be sent out wnen an ETH-LCK event occurs or clears.
state – Specify the state of the CFM trap.
enable – Enable the CFM trap state. This is the default.
disable – Disable the CFM trap state.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
