xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

240

Example

To set the authentication server failover state:

DGS-3420-28SC:admin#config authentication server failover local

Command: config authentication server failover local

Success.

DGS-3420-28SC:admin#
