xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

331

DGS-3420-28SC:admin#

To delete an option profile from a DHCP pool:

DGS-3420-28SC:admin#config dhcp pool option_profile pool1 delete profile1

Command: config dhcp pool option_profile pool1 delete profile1

Success.

DGS-3420-28SC:admin#
