xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

373

Restrictions

Only Administrator and Operator-level users can issue this command.

Example

To configure the DDM TX and RX power unit as dBm:

DGS-3420-28SC:admin#config ddm power_unit dbm

Command: config ddm power_unit dbm

Success.

DGS-3420-28SC:admin#
