xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
453
vlanid - Specify the VLAN ID list.
<vlanid_list> - Specify the VLAN ID list.
<ipaddr> - Specify the multicast group IP address.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create an IGMP snooping static group on default VLAN, group 239.1.1.1:
DGS-3420-28SC:admin#create igmp_snooping static_group vlan default 239.1.1.1
Command: create igmp_snooping static_group vlan default 239.1.1.1
Success.
DGS-3420-28SC:admin#
39-13 config igmp_snooping static_group
Description
This command is used to configure an IGMP snooping static group on the switch. When a port is
configured as a static member port, the IGMP protocol will not operate on this port. Therefore,
suppose that a port is a dynamic member port learned by IGMP. If this port is configured as a static
member later, then the IGMP protocol will stop operating on this port. The IGMP protocol will resume
once this port is removed from static member ports. The static member port will only affect V2 IGMP
operation.
Format
config igmp_snooping static_group [vlan <vlan_name 32> | vlanid <vlanid_list>] <ipaddr> [add
| delete] <portlist>
Parameters
vlan - Specify the name of the VLAN on which the static group resides.
<vlan_name 32> - Specify the VLAN name. The maximum length is 32 characters.
vlanid - Specify the ID of the VLAN on which the static group resides.
<vlanid_list> - Specify the VLAN ID list.
<ipaddr> - Specify the multicast group IP address.
add - Specify to add the member ports.
delete - Specify to delete the member ports.
<portlist> - Specify a range of ports to be configured.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
