xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
560
01-00-0C-CC-CC-CC - Specify to use this protocol MAC address.
01-00-0C-CC-CC-CD - Specify to use this protocol MAC address.
all - Specify to use all the MAC addresses.
threshold - (Optional) Specify the drop threshold for packets-per-second accepted on this UNI port.
The port drops the PDU if the protocol’s threshold is exceeded. The range of the threshold value
is 0 to 65535 (packet/second). The value 0 means on limit. By default, the value is 0.
<value 0-65535> - Enter the threshold packets-per-seconds value here. This value must be
between 0 and 65535.
nni - Specify the port is NNI port
none - Disables tunnel on it. By default, a port is none port.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the STP tunneling on ports 1-4:
DGS-3420-28SC:admin# config l2protocol_tunnel ports 1-4 type uni tunneled_protocol
stp
Command: config l2protocol_tunnel ports 1-4 type uni tunneled_protocol stp
Success.
DGS-3420-28SC:admin#
48-2 show l2protocol_tunnel
Description
This command is used to show Layer 2 protocol tunneling information.
Format
show l2protocol_tunnel {[uni | nni]}
Parameters
uni - (Optional) Specify show UNI detail information, include tunneled and dropped PDU statistic.
nni - (Optional) Specify show NNI detail information, include de-capsulated Layer 2 PDU statistic.
Restrictions
None.
Example
To show Layer 2 protocol tunneling information summary:
